English

RECONDITIONED PRODUCT: Reconditioned product is

covered under the 1 Year Free Service Warranty. The 90

Day Money Back Guarantee and the Three Year Limited

Warranty do not apply to reconditioned product.

FREE WARNING LABEL REPLACEMENT: If your

warning labels become illegible or are missing, call

1-800-4-D

EWALT for a free replacement.

Patent Notification

Manufactured under one or more of the following U.S.

patents:

6,823,765 6,101,914 5,907,987 5,375,495

6,810,780 6,035,754 5,862,734 5,285,708

6,520,059, 6,032,563 5,582,089 5,199,343

Other patents may be pending.

Troubleshooting Guide

BE SURE TO FOLLOW SAFETY RULES AND INSTRUCTIONS

TROUBLE! WHAT’S WRONG? WHAT TO DO

SAW WILL NOT START

1. Saw not plugged in 1. Plug in saw

2. Fuse blown or circuit breaker

tripped

2. Replace fuse or reset circuit breaker

3. Cord damaged 3. Have cord replaced by authorized ser-

vice center

4. Brushes worn out 4. Have brushes replaced by authorized

service center or replace them yourself

as instructed on page 9.

SAW MAKES

UNSATISFACTORY CUTS

1. Dull blade 1. Replace blade, see page 6.

2. Blade mounted backwards 2. Turn blade around, see page 6.

3. Gum or pitch on blade 3. Remove blade and clean with turpen-

tine and coarse steel wool or house-

hold oven cleaner

4. Incorrect blade for work being done 4. Change the blade type, see pages 5.

BLADE DOES NOT COME UP

TO SPEED

1. Extension cord too light or too long 1. Replace with adequate size cord, see

page 2.

2. Low house current 2. Contact your electric company

MACHINE VIBRATES

EXCESSIVELY

1. Saw not mounted securely to stand

or work bench

1. Tighten all mounting hardware, see

page 6.

2. Stand or bench on uneven floor 2. Reposition on flat level surface, see

page 6.

3. Damaged saw blade

3. Replace blade, see page 7.

DOES NOT MAKE ACCURATE

MITER CUTS

1. Miter scale not adjusted correctly 1. Check and adjust, see page 8.

2. Blade is not square to fence 2. Check and adjust, see page 8.

3. Blade is not perpendicular to table 3. Check and adjust fence, see page 8.

4. Workpiece moving 4. Clamp workpiece securely to fence or

glue 120 grit sandpaper to fence with

rubber cement.

MATERIAL PINCHES BLADE

1. Cutting bowed material 1. Position bowed material as shown on

page 13.
