DW680-XEHEAVY-DUTY 82 MM PLANERINSTRUCTION MANUAL

8GuaranteeApplicable to hand held Power Tools, Lasers and Nailers.Three Year Limited WarrantyDEWALT will repair, without charge, any defects due to fa

9FREE WARNING LABEL REPLACEMENT: If your warning labels become illegible or are missing, call (AUS) 1800 654 155 or (NZ) 0800 339258 for a free replac

DEWALT Industrial Tool Co., 701 East Joppa Road, Baltimore, MD 21286 • 20 Fletcher Road, Mooroolbark, VIC 3138 Australia(AUG10) Part No. N09

1Definitions: Safety Guidelines The definitions below describe the level of severity for each signal word. Please read the manual and pay attention to

2c. Avoid accidental starting. Ensure the switch is in the off position before plugging in. Carrying power tools with your finger on the switch or pl

3MINIMUM GAUGE FOR CORD SETSFor Cable length (m): 7.5 15 25 30 45 60Use Cable with minimum rating (Amperes)Tool Amperes 0 - 3.4 7.5 7.5 7.5

4Components (Fig. 1) A. Trigger switch E. Shoe B. Lock-on button F. Rabbet fence (not shown) C. Depth adjustment knob/front handle G. Rabbet fe

5CAUTION: Allow the tool to reach full speed before touching tool to the work surface. Lift the tool from the work surface before turning the tool off

6To Install Rabbet Fence 1. Loosen the rabbet fence adjustment knob (G). 2. Slide the crossbar on the rabbet fence (F) into the hole near the fron

7 d. Simultaneously push the blade carrier (L) and the guide bar (M) into the gauge plate inside wall (O), making sure that the carbide blade (I)
